With every detail, DJI RS 3 delivers a flexible and efficient shooting experience to solo creators and independent crews. Light and sleek, it provides professional stabilization and efficient control for more creative freedom and endless possibilities. DJI RS 3 is ready when you are. Explore more at Everse.
Quick-Release Plates
With dual-layered quick-release plates, mounting a camera onto RS 3 is fast and convenient, with no need to re-balance the gimbal after swapping out a new battery or memory card. Learn more at DJI Camera Drones.
Automated Axis Locks
RS 3 lets you get up and running instantly. When the gimbal is powered off, press and hold the power button, and the three axes unlock while the gimbal expands automatically. For more accessories, visit Accessories.
Wireless Shutter Control
By implementing Dual-Mode Bluetooth, RS 3 supports wireless shutter control, saving time and enhancing the shooting experience. Check out more at Action Cameras.
Excellent Weight-to-Payload Ratio
Weighing only 1.3 kg/2.8 lbs, RS 3 can be held easily in one hand, while its 3kg/6.6lb load capacity supports mainstream cameras. For detailed services, visit Everse Services.
Beyond Smooth
When you need even smoother results, turn on SuperSmooth mode. RS 3 will increase motor torque to further enhance stabilization, delivering stable footage. Explore more on Everse Blogs.
1.8″ OLED Touchscreen
Compared with the black and white screen of RSC 2, RS 3 features a 1.8-inch OLED full-color touchscreen with an 80% larger display.
Instant Mode Switching
By sliding the new gimbal mode switch, you can alternate between Pan follow, Pan and Tilt follow, and FPV modes, ensuring quick adaptation for various shooting styles.
Customizable Front Dial
Rotating the front dial allows you to control zoom or focus. It can also be customized to control the camera’s shutter, aperture, and ISO, ensuring effortless single-handed operation.
Monitoring via Smartphone
RS 3 supports the Ronin Image Transmitter to transmit 1080p/30fps HD live feeds directly to a mobile device. You can also remotely adjust camera exposure or control the gimbal through the Ronin app.
- NATO Ports: Available
- 1/4″-20 Mounting Hole: Available
- Cold Shoe: Available
- Video Transmission/Focus Motor Port (USB-C): Available
- RSS Camera Control Port (USB-C): Available
- Focus Motor Port (USB-C): Available
- Model: BHX711-3000-7.2V
- Type: 2S
- Capacity: 3000 mAh
- Energy: 21 Wh
- Max. Runtime: 12 hours [1]
- Charging Time: Approx. 2.5 hours when using 18W quick charging (supports PD protocol)
- Suggested Charging Temperature: 5° to 40° C (41° to 104° F)
- Bluetooth: 5.0
- Charging Port: USB-C
- iOS: 11.0 or above
- Android: 7.0 or above
- Languages: English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai
- Tested Payload
3 kg (6.6 lbs) - Maximum Controlled Rotation Speed
Pan: 360°/s | Tilt: 360°/s | Roll: 360°/s - Mechanical Range
Pan: 360° continuous
Roll: -95° to +240°
Tilt: -112° to +214°
- Operating Frequency
2.400-2.484 GHz - Bluetooth Transmitter Power
<8 dBm - Operating Temperature
-20° to 45° C (-4° to 113° F) - Weight
Gimbal: Approx. 990 g (2.18 lbs)
Grip: Approx. 200 g (0.44 lbs)
Extended Grip/Tripod (Plastic): Approx. 183 g (0.4 lbs)
Upper and Lower Quick-Release Plates: Approx. 107 g (0.23 lbs) - Dimensions
Folded: 254×230×68 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod)
Unfolded: 364×187×170 mm (L×W×H, height includes the grip and excludes the Extended Grip/Tripod)
- Connections
Power/Communication Port (USB-C)
HDMI Port (Mini HDMI)
RSS Camera Control Port (USB-C)
Expansion Port
Cold Shoe - Operating Frequency
2.400-2.484 GHz
5.725-5.850 GHz - Weight
126 g (0.27 lbs) - Dimensions
82×63×24 mm - Transmitter Power (EIRP)
2.400-2.484 GHz:
<25 dBm (FCC)
<20 dBm (CE/SRRC/MIC)
5.725-5.850 GHz:
<25 dBm (FCC/SRRC)
<14 dBm (CE) - Battery
Capacity: 2970 mAh
Compatible Charger: 5V/2A
Charging Time: Approx. 2.5 hours
Max Battery Life: Approx. 3.5 hours - Transmission Range
200 m (SRRC/FCC) [2]
100 m (CE) [2] - Latency
60 ms - Operating Current/Voltage
900 mA, 3.7V - Operating Temperature
0° to 45° C (32° to 113° F)
