Elevate Your Aerial Mapping Missions
When you map land survey structures or inspect a corridor you want accuracy. You want reliable data. You want to finish your work faster without sacrificing detail.
Zenmuse L3 gives you long-range LiDAR dual 100MP cameras and a high-precision positioning system in one setup. You fly once. You collect clean data. You move to the next site without delay.
If you lead surveying teams, handle critical terrain projects or support emergency response, this tool helps you deliver results your clients can trust.
What You Experience With Zenmuse L3
You cover more ground quickly.
You see beneath trees and dense areas clearly.
You fly higher and still record sharp terrain details.
You operate in one workflow from capture to deliverables.
Your workday becomes more productive.
Your output becomes more reliable.
Your confidence during mapping missions grows.
Key Features
- Long-range LiDAR up to 950 m on low-reflective surfaces
- Dual 100MP mapping cameras with mechanical shutter
- High-precision POS for survey-grade results
- Up to 2M laser pulses per second
- Up to 16 returns for dense vegetation and complex sites
- Three scan modes: linear star-shaped non-repetitive
- Real-time point cloud preview and cloud sync support
- Works with DJI Matrice 400 platform
- Up to 100 km² mapping coverage per day
Why It Fits Your Work
Map Faster With Long-Range LiDAR
Fly at 300–500 m and still capture ground details clearly. You complete wider zones in fewer flights.
Reveal Critical Ground Points
Small laser spot captures terrain under trees and thick vegetation. Helpful for earthwork planning forestry mining and slope assessment.
Capture True Color and Detail
Dual cameras build sharp imagery for DEM and DOM output in one mission.
Stay Reliable in Demanding Surveys
Strong positioning accuracy brings confidence to high-value sites.
Perfect For
- Land surveying firms
- Construction and earthwork projects
- Mining and quarry mapping
- Power line and utility inspection
- Forestry management
- Emergency mapping and disaster study
- Government and infrastructure planning teams
If your work affects land people or public assets accuracy matters. Zenmuse L3 helps you deliver it without compromise.
Specification
| LiDAR Range | Up to 950 m |
| Wavelength | 1535 nm |
| Pulse Rate | Up to 2M pulses/s |
| Returns | Up to 16 returns |
| Beam Divergence | 0.25 mrad |
| Cameras | Dual 100MP 4/3 CMOS |
| Field of View | Up to 107° HFOV |
| Ground Accuracy | Up to ~3 cm (typical survey altitude) |
| Flight Coverage | Up to 100 km²/day |
| POS Accuracy | Heading 0.02°, Pitch 0.01° (post-processed) |
| Platform Compatibility | DJI Matrice 400 |
| Workflow | LiDAR + RGB + POS + DJI Terra |
What You Get From Each Flight
- High-density point clouds
- Precise terrain models
- True-color orthomaps
- Accurate elevation data
- Structural clarity in corridors and industrial zones
- Confidence to deliver survey-grade reports
You save time. Your team works smarter. Your clients see better results and trust your expertise.
Ready to Deploy in the Field
Zenmuse L3 brings surveying, imaging, and processing into one system. You lift off capture everything in one run, and get reliable data in less time. If you build measure or protect land this tool supports your mission with clarity and control.
